Specifications
Manufacturer specifications vary by configuration. Contact sales to confirm the offered variant and availability.
Engine & Performance
Engine
Engine specifications| Engine | 1.5 L, 3 Cylinder Diesel Engine Type Turbo Charged, with Intercooler |
|---|
| Displacement/Cubic Capacity | 1,478 cc |
|---|
| Maximum Power kW (@ rpm) | 59 kW(80 hp) @ 3,300 RPM |
|---|
| Maximum Torque Nm (@ rpm) | 190 Nm @ 1,600-2,400 rpm |
|---|
Clutch
Clutch specifications| Clutch | 240 mm Diameter, Diaphragm, Single Dry Plate, Mechanical Cable Operated |
|---|
Engine & Performance
Engine
- Engine
- 1.5 L, 3 Cylinder Diesel Engine Type Turbo Charged, with Intercooler
- Displacement/Cubic Capacity
- 1,478 cc
- Maximum Power kW (@ rpm)
- 59 kW(80 hp) @ 3,300 RPM
- Maximum Torque Nm (@ rpm)
- 190 Nm @ 1,600-2,400 rpm
Clutch
- Clutch
- 240 mm Diameter, Diaphragm, Single Dry Plate, Mechanical Cable Operated
Load & Dimensions
Dimensions
- Wheelbase
- 2,740 mm
- Overall length
- 5,325 mm
- Overall width
- 1,842 mm
- Overall Height
- 2,048 mm
- Load body dimension (FSD)
- LxBxH : ( 3,250 X 1,750 X 490 ) mm (10 ft 8 in X 5 ft 9 in X 1 ft 7 in)
- Loading platform height
- 932 mm
Weight
- GVW(kg)
- 3,490
- Payload(kg)
- 1,758
Chassis
Steering
- Steering Type
- Power Assisted, Tiltable Column
Suspension
- Front
- Rigid front Suspension (5 leaf) with Anti roll Bar
- Rear
- Semi elliptic Leaf suspension (8 Leaf)
