Specifications
Manufacturer specifications vary by configuration. Contact sales to confirm the offered variant and availability.
Engine & Performance
Engine
Engine specifications| Engine | 1.5L,3 Cylinder CNG engine |
|---|
| Engine type | Turbo Charged Intercooled |
|---|
| Displacement (Cubic Capacity) | 1,478 cc |
|---|
| Maximum Power kW (@ rpm) | 43.2 kW(58 hp) @ 3,300 RPM |
|---|
| Maximum Torque Nm (@ rpm) | 160 Nm @ 1,600-2,400 rpm |
|---|
Clutch
Clutch specifications| Type | Single Plate, Dry Type, Mechanical Actuation |
|---|
Engine & Performance
Engine
- Engine
- 1.5L,3 Cylinder CNG engine
- Engine type
- Turbo Charged Intercooled
- Displacement (Cubic Capacity)
- 1,478 cc
- Maximum Power kW (@ rpm)
- 43.2 kW(58 hp) @ 3,300 RPM
- Maximum Torque Nm (@ rpm)
- 160 Nm @ 1,600-2,400 rpm
Clutch
- Type
- Single Plate, Dry Type, Mechanical Actuation
Load & Dimensions
Dimensions (mm)
- Wheelbase
- 2,510 mm
- Overall Length
- 4,770 mm
- Overall Height
- 1,930 mm
- Load Body/ Cargo Deck (LxBxH)
- (2,805x1,620x440) mm (9ft 2in X 5ft 4in X 1ft 5in)
- Loading Platform Height
- 945 mm (3.1ft)
Weight
- Gross Vehicle Weight (GVW)
- 2,905 kg
- Rated Payload
- 1,400 kg
Chassis
Steering
- Type
- Power Steering
Suspension
- Front
- Parabolic Leaf Spring with Double Acting Shock Absorber
- Rear
- Parabolic Leaf Spring with Double Acting Shock Absorber
Cabin & Equipment
