Specifications
Manufacturer specifications vary by configuration. Contact sales to confirm the offered variant and availability.
Engine & Performance
Engine
Engine specifications| Engine | ZD30 DDTi common rail diesel engine |
|---|
| Displacement | 2,953 cc |
|---|
| Maximum Power Output | 104.3 kW (140 hp) @ 2,750 rpm |
|---|
| Maximum Torque | 360 Nm @ 1,350-2,750 rpm |
|---|
Clutch
Clutch specifications| Clutch | 310 mm diameter, diaphragm push type, single dry plate, hydraulic actuated |
|---|
Transmission
Transmission specifications| Transmission | Fully synchronised 5-speed manual gearbox |
|---|
Engine & Performance
Engine
- Engine
- ZD30 DDTi common rail diesel engine
- Displacement
- 2,953 cc
- Maximum Power Output
- 104.3 kW (140 hp) @ 2,750 rpm
- Maximum Torque
- 360 Nm @ 1,350-2,750 rpm
Clutch
- Clutch
- 310 mm diameter, diaphragm push type, single dry plate, hydraulic actuated
Transmission
- Transmission
- Fully synchronised 5-speed manual gearbox
Load & Dimensions
Fuel System
- Fuel tank capacity
- 90 litres
Weight
- GVW(kg)
- 6,250 kg (10 ft); 7,200 kg (14 ft)
- Payload(kg)
- 3,760 kg (10 ft FSD); 4,565 kg (14 ft FSD)
FSD payload: 3,760 kg with the 3,160 mm load body; 4,565 kg with the 4,230 mm load body. Confirm the offered variant with sales.
Dimensions
- Load body length
- 3,160 mm (10 ft); 4,230 mm (14 ft)
- Wheelbase
- 2,685 mm (10 ft); 3,335 mm (14 ft)
Chassis
Steering
- Steering Type
- Power Steering
Brakes
- Service brake
- Vacuum-assisted hydraulic brake (10 / 14 ft)
