Specifications
Manufacturer specifications vary by configuration. Contact sales to confirm the offered variant and availability.
Engine & Performance
Engine
Engine specifications| Engine | ZD30 DDTi common rail diesel engine |
|---|
| Displacement | 2,953 cc |
|---|
| Maximum Power Output | 104.3 kW (140 hp) @ 2,750 rpm |
|---|
| Maximum Torque | 360 Nm @ 1,350-2,750 rpm |
|---|
Clutch
Clutch specifications| Clutch | 310 mm diameter, diaphragm push type, single dry plate, hydraulic actuated |
|---|
Transmission
Transmission specifications| Transmission | Fully synchronised 5-speed manual gearbox |
|---|
Engine & Performance
Engine
- Engine
- ZD30 DDTi common rail diesel engine
- Displacement
- 2,953 cc
- Maximum Power Output
- 104.3 kW (140 hp) @ 2,750 rpm
- Maximum Torque
- 360 Nm @ 1,350-2,750 rpm
Clutch
- Clutch
- 310 mm diameter, diaphragm push type, single dry plate, hydraulic actuated
Transmission
- Transmission
- Fully synchronised 5-speed manual gearbox
Load & Dimensions
Fuel System
- Fuel tank capacity
- 90 litres
Weight
- GVW(kg)
- 7,490 kg (11 ft and 14 ft)
- Payload(kg)
- 4,885 kg (11 ft FSD); 4,775 kg (14 ft FSD)
Dimensions
- Load body length
- 3,415 mm (11 ft); 4,230 mm (14 ft)
- Wheelbase
- 2,820 mm (11 ft); 3,320 mm (14 ft)
Chassis
Steering
- Steering Type
- Power Steering
Brakes
- Service brake
- Vacuum-assisted hydraulic brake (11 / 14 ft; refer to separate brochure for 17 ft)
Cabin & Equipment
Variant Type
- Type
- CBC, FSD, HSD
