Specifications
Manufacturer specifications vary by configuration. Contact sales to confirm the offered variant and availability.
Engine & Performance
Engine
Engine specifications| Engine | ZD30 DDTi common rail diesel engine |
|---|
| Displacement | 2,953 cc |
|---|
| Maximum Power Output | 104.3 kW (140 hp) @ 2,750 rpm |
|---|
| Maximum Torque | 360 Nm @ 1,350-2,750 rpm |
|---|
Clutch
Clutch specifications| Clutch | 310 mm diameter |
|---|
Transmission
Transmission specifications| Transmission | Fully synchronised 5-speed manual gearbox |
|---|
Engine & Performance
Engine
- Engine
- ZD30 DDTi common rail diesel engine
- Displacement
- 2,953 cc
- Maximum Power Output
- 104.3 kW (140 hp) @ 2,750 rpm
- Maximum Torque
- 360 Nm @ 1,350-2,750 rpm
Clutch
- Clutch
- 310 mm diameter
Transmission
- Transmission
- Fully synchronised 5-speed manual gearbox
Load & Dimensions
Fuel System
- Fuel tank capacity
- 90 litres
Weight
- GVW(kg)
- 6,650 kg (3,700 mm WB); 7,200 kg (4,270 mm WB)
Dimensions
- Wheelbase
- 3,700 mm (7 m); 4,270 mm (8 m)
- Overall dimensions (L x W x H)
- 7,060 x 2,200 x 2,630 mm (3,700 mm WB); 7,970 x 2,200 x 2,630 mm (4,270 mm WB)
- Overall height (AC)
- 2,850 mm (both wheelbases)
Chassis
Steering
- Steering Type
- Power Steering
Brakes
- Service brakes
- Dual-circuit hydraulic brakes with vacuum assist
Cabin & Equipment
Seating
- Seating capacity
- 22–45 students, plus assistant and driver; configuration dependent
- 3,700 mm WB: 2 x 2 (Non-AC / AC)
- 22 high-back (single door); 26 standard (single door); 24 standard (double door)
- 3,700 mm WB: 3 x 3 (Non-AC / AC)
- 39 standard (single door); 36 standard (double door)
- 3,700 mm WB: 3 x 2 (Non-AC only)
- 33 standard (single door); 31 standard (double door)
- 4,270 mm WB: 2 x 2 (Non-AC / AC)
- 30 standard (single door); 28 standard (double door)
- 4,270 mm WB: 3 x 3 (Non-AC / AC)
- 45 standard (single door); 42 standard (double door)
- 4,270 mm WB: 3 x 2 (Non-AC only)
- 38 standard (single door); 36 standard (double door)
