Specifications
Manufacturer specifications vary by configuration. Contact sales to confirm the offered variant and availability.
Engine & Performance
Engine
Engine specifications| Engine | 1.5 L, 3 Cylinder Diesel Engine (BS VI) |
|---|
| Engine Type | Turbo Charged Intercooled |
|---|
| Displacement/Cubic Capacity | 1,478 cc |
|---|
| Maximum Power kW (@ rpm) | 59 kW(80 hp) @ 3,300 RPM |
|---|
| Maximum Torque Nm (@ rpm) | 190 Nm @ 1,600-2,400 rpm |
|---|
Clutch
Clutch specifications| Clutch | Diaphragm, Single Dry Plate, Mechanical Cable Operated |
|---|
Engine & Performance
Engine
- Engine
- 1.5 L, 3 Cylinder Diesel Engine (BS VI)
- Engine Type
- Turbo Charged Intercooled
- Displacement/Cubic Capacity
- 1,478 cc
- Maximum Power kW (@ rpm)
- 59 kW(80 hp) @ 3,300 RPM
- Maximum Torque Nm (@ rpm)
- 190 Nm @ 1,600-2,400 rpm
Clutch
- Clutch
- Diaphragm, Single Dry Plate, Mechanical Cable Operated
Load & Dimensions
Dimensions
- Wheelbase
- 2,740 mm
- Overall length
- 5,325 mm
- Overall width
- 1,842 mm
- Overall Height
- 2,048 mm
- Load body dimension (FSD)
- LxBxH: (3,250 X 1,750 X 490)mm (10ft 8in X 5ft 9in X 1ft 7in)
- Loading platform height
- 932 mm (3.06ft)
Chassis
Steering
- Steering Type
- Power Steering
Suspension
- Front
- Rigid Front Suspension (5 leaf) with Anti-roll Bar
- Rear
- Semi Elliptic Leaf Suspension (8 Leaf)
Dimensions
- Tyres Size/Type
- 7.00 R15 LT 12 PR
Cabin & Equipment
Weight
- Payload (FSD LX Variant)
- 2,357 kg
- Payload (CBC LX Variant)
- 2,567 kg
